ULO-CC02-M8X-XXP-MM-SD-SH002
ULO-CC02-M8X-XXP-MM-SD-SH002 M8 sensor/actuator female socket designed for reliable circular connector wiring, featuring pin options 3/4/5/6/8Pin, rated current 1.5A(6/8Pin) 3A(3/4/5Pin), rated voltage 30V(5/6/8Pin) 60V(3/4Pin), protection level IP67.
Certifications
Core Applications
ULO-CC02-M8X-XXP-MM-SD-SH002
ULO-CC02-M8X-XXP-MM-SD-SH002 M8 sensor/actuator female socket designed for reliable circular connector wiring, featuring pin options 3/4/5/6/8Pin, rated current 1.5A(6/8Pin) 3A(3/4/5Pin), rated voltage 30V(5/6/8Pin) 60V(3/4Pin), protection level IP67.
Product Overview
The ULO-CC02-M8X-XXP-MM-SD-SH002 is a sensor/actuator female socket for M-series circular connector applications. Key specifications include Number of potentials: 3/4/5/6/8Pin, Rated current: 1.5A(6/8Pin) 3A(3/4/5Pin), Rated voltage: 30V(5/6/8Pin) 60V(3/4Pin), Protection level: IP67. Product design details include Contact material: CuZn, Contact surface: Au, Contact carrier material: PA, Sealing material: Silicon, Flammability rating: UL94V-0. Use it for compact sensor, actuator and industrial field wiring where a secure circular connection is required.
Product Family
Key Features
Compact M8 Connection
M8 circular connector design provides reliable signal connection while saving space for compact industrial devices.
IP67 Field Protection
Sealed structure supports protection up to IP67 when locked, helping ensure stable performance in demanding field environments.
Flexible Product Options
Available in overmolded cable, panel mount, and field assembly types, with male/female, straight/angled, shielded/unshielded, and A-coded or B-coded options.
Typical Applications
Sensor & Actuator Wiring
Ideal for connecting proximity sensors, photoelectric sensors, limit switches, actuators, and other field devices.
Industrial Automation Equipment
Suitable for compact signal connection in automated machines, control systems, and distributed I/O applications.
Panel & Device Interfaces
Used as reliable panel-mounted interfaces for controllers, instruments, I/O modules, and electronic equipment.
Harsh Field Environments
Supports stable wiring in applications with vibration, shock, moisture, and limited installation space.
